Chapter
4
Geometric
Representations
for Arbitrary Hierarchies
In the last chapter, we saw the complex
mechanics of classical central place theory come alive as a single
dynamic
system when viewed through the lens of fractal geometry. The fit
of the classical and fractal geometric hierarchies is exact.
Thus,
as one might use a carefully surveyed topographic map, with
fieldchecked
spot elevations, as a guide into dense jungle or other unsurveyed
landscapes,
so too we use our carefully field checked alignment of the classical
and
the fractal as a guide into unseen or unproven areas of theoretical
geography.
The difference is that the "field" tests in one case occur in
"terrestrial
space" while in the other the "field" tests occur in "geometry, number
theory, and pure mathematics."
We saw hexagonal hierarchies, of
different
orientation, cell size, and stacking characteristics, arise from the
same
base of unit hexagons. These were associated with three
integers:
3, 4, and 7. The thoughtful reader might naturally ask a number
of
questions, such as:
 are there other numbers that would
serve as K
values or are 3, 4, and 7 the only such values?
 are 5 or 6 possible K
values?
 are there K values
larger
than 7?
 how many K values are
there?
Dacey
considered these issues.  How
does one determine the number of
sides
in a fractal generator that will generate a correct hierarchy for
arbitrary K
values?
 How does one determine fractal
generator shape
that will generate a correct hierarchy for arbitrary K values?
In this chapter we offer geometric
representations
for higher numerical K values. Subsequent chapters will
develop
the number theory required to execute these constructions.
Coordinatization
of
the triangular lattice
Previous
chapters employed a lattice of points to represent central places as a
synthetic (coordinatefree) system. It is straightforward to
assign
a coordinate system, as well. If a point is given the usual
Euclidean
coordinate (x,y), based on perpendicular axes, its distance from
the origin is easily calculated to be (x^{2} + y^{2})^{1/2}.
Thus, there is a natural association of the quadratic expression x^{2}
+ y^{2} with the point (x,y). Such
an
expression is sometimes called a quadratic form. Quadratic forms
have been studied extensively and material about them will appear in
Chapter
5.
When the plane is
occupied by a set of hamlets, each equidistant from its nearest
neighbors,
it seems more reasonable to pick a coordinate system which gives
coordinates
(0,0), (1,0), and (0,1) to three hamlets which are vertices of an
equilateral
triangle. Thus it is natural to have a horizontal
xaxis and
a yaxis at angle 60Â° to the xaxis, as
illustrated in
Figure 4.1. Now, however, the calculation of distance between a
point
with coordinates (x,y) and the origin (0,0) is more
complicated.
Figure 4.1 illustrates the situation when x and y are
both
positive. The right triangle whose hypotenuse has length this
distance
now has vertical side of length y/2
and horizontal side of length y/2+x. Thus the
distance,
d,
is
The quadratic form
x^{2
}+
xy
+ y^{2} is thus associated with the vertex
(x,y)
as both Dacey and Loeb
had suggested earlier.
Figure 4.1.
The standard yaxis of Cartesian coordinates is shown in cyan
(turquoise).
The yellow lines show the oblique axes. The value d
represents
the distance between the origin and an arbitrary point, (x,y),
drawn in this case on the line y = x of the oblique
axes.
The illustration in Figure 4.1 shows
both values as positive. Thus, it must be established that this
distance
is the same even when
x and
y are not both positive.
When
x and y are both negative. x must be
substituted for x, and y must be substituted for y,
but the calculation remains the same.
When exactly one
of x or y becomes negative, the geometry is
different.
Now the vertical side of the relevant right triangle has side of length
y/2
but the horizontal side is now of length
xy/2.
Thus the appropriate distance is
When x
is negative and y is positive, a
similar
calculation results.
Thus the form x^{2
}+
xy
+ y^{2} is indeed associated with the vertex
(x,y)
in this coordinate system. Any positive integer that is equal to
x^{2
}+
xy
+ y^{2} for some integers x
and y is called
Löschian,
after August Lösch.
One mathematical question that then occurs is: what integers are
Löschian? The next chapter (Chapter 5)
develops the number theory
necessary to answer that question. Other issues involve values of
K
greater than 7 as well as questions involving number of generator sides
and generator shape mentioned above. The rest of this chapter
deals
with these items.
Higher Kvalues:
An Infinite Number
Earlier research, by
August Lösch,
Michael Dacey,
and others shows illustrations of Kvalues greater than
7.
Indeed, research by Arthur Loeb,
in crystallography, and Dacey,
in
geography, led to independent discovery that the Diophantine
equation, x^{2}+xy+y^{2} = K
would generate all K values when pairs of positive integers
were
substituted for x and for y. Thus, when (x,y)=(1,1)
the equation x^{2}+xy+y^{2} = K
yields
a value of K=3; when (x,y)=(0,2), it follows that
K=4;
and, when (x,y)=(1,2), it follows that K=7.
Pairs such as (0,0) and (1,0) yield only trivial results so that the
values
of 3, 4, and 7 are the three smallest Kvalues. There are
no other K values less than 7.
The result of Loeb/Dacey is important
because
it shows
 that there is an infinite number
of
possible K
values
 that this infinity of values is in
onetoone
correspondence with the integral lattice points in the plane
 that one can give a numerical
generating function
to create K values
Thus, a graph of lattice points in the
plane
offers a convenient method of visualizing Kvalues larger than
7
(Figure 4.2).
Figure 4.2.
The coordinatized lattice points in yellow transform into Kvalues
in cyan using the Diophantine equation K=x^{2}+xy+y^{2}
The
Diophantine
equation, x^{2}+xy+y^{2} = K,
is
symmetric: the points (1,2) and (2,1) represent different
locations
in the plane. They both generate the same K value.
Thus,
it suffices to consider only a portion of the available lattice
points:
those in the first quadrant on one side of the line y=x. Because
the pattern of points associated with central place hierarchies is
based
on a triangular lattice, the graph of lattice points displayed in
Figure
4.2 is based on an oblique, rather than on a rectangular, coordinate
system
with angles at the origin of 60 and 120 degrees. Combining
considerations
of symmetry and oblique coordinates led to Figure 4.2. In that
figure,
both coordinate pairs, and corresponding Kvalue generated by
the
Diophantine equation, are shown.
With an
infinite
number of Kvalues available, it is a daunting consideration to
try to figure out how to create a nested hierarchy of hexagonal trade
areas
suited to each value of K. Simple drawing skills do not
suffice.
One needs a formal strategy that can be replicated at will.
Fractal
geometry will offer that capability.
In the previous chapter, fractal
generators
appear simply to be plucked out of thin air: there is art in
generator
selection. Actually, the generator for the K=7 hierarchy
suggested
itself naturally with observations of overfit/underfit of the six small
hexagons in relation to the boundary of the next larger one (Figure
4.3).
From there, it was simply a matter of educated guessing and trial and
error
to find generators for K=3 and K=4 hierarchies.
Someone
with considerable experience working with this approach might, for
example,
figure out a fractal generator for a K=76 hierarchy, associated
with the lattice point (4,6) (Figure 4.4). For replication by
arbitrary
individuals to be successful, however, one needs to capture the art in
the formalized theory and language of mathematics: to transform
art
into science.
Figure
4.3.
Overfit and underfit of small to larger hexagons emphasized:
fractal
generator, a zigzag three sided shape, emerges from such observation.

Figure 4.4.
K=76
fractal generation; corresponding lattice point has coordinates
(4,6).
The generator shape appears at the edge.
Fractal
Generation
of Arbitrary KValues: Geometric Evidence
Once one
generator
shape is known, can it be used to determine other generator
shapes?
The answer is yes. The table in Table 4.1 illustrates that the K=3
generator, with a half a "hexstep" added, leads to the K=7
generator.
K=3
generator.

K=3
generator
(red) with one half hexstep added (green).

K=7
generator

Table 4.1. The K=3
generator
leads to the K=7 generator.
To try to
uncover
pattern useful in creating fractal generators for arbitrary K
values,
we begin by looking at a subset of K values: those along
the
yaxis,
only. In that case, because
x^{2}+xy+y^{2}
= 0 + 0 + y^{2} = K , it follows that
the square
root of K is an integer and that the lattice points (0,y)
on the yaxis may be rewritten as (0, ).
Trial and error with finding fractal generators for selected values
along
the yaxis produced the table of generators shown in Figure
4.5.
The trivial value of K=1, associated with the point (0,1) is
not
shown in this figure. Within that "trial and error" process a
pattern
emerged, demonstrated in the animated Figure 4.5.
 Begin with the K=4
generator
(lowest
value on the yaxis): generator in red.
 To the previous generator, add a
full hexstep
to the left of it and a half hexstep, curled under, to the right:
generator in green. This new generator produces the K=9
hierarchy.
 To the previous generator, add a
half hexstep
to the left (flat portion of the step): generator in blue.
This new generator produces the K=16 hierarchy.
 Add two full hexsteps, one on each
side, to
the K=4 generator, creating a symmetric generator that produces
the K=25 hierarchy.
 To the previous generator, add a
full hexstep
to the left of it and a half hexstep, curled under, to the right:
generator in green. This new generator produces the K=36
hierarchy.
 To the previous generator, add a
half hexstep
to the left (flat portion of the step): generator in blue.
This new generator produces the K=49 hierarchy.
 Add two full hexsteps, one on each
side, to
the K=25 generator, creating a symmetric generator that
produces
the K=64 hierarchy.
 To the previous generator, add a
full hexstep
to the left of it and a half hexstep, curled under, to the right:
generator in green. This new generator produces the K=81
hierarchy.
 To the previous generator, add a
half hexstep
to the left (flat portion of the step): generator in blue.
This new generator produces the K=100 hierarchy.
Lattice Coordinate
Kvalue (yaxis values)
Generator Shape
Hierarchy Type
(0,2)
K=4

4
(0,3)
K=9

3
(0,4)
K=16

7
(0,5)
K=25

4
(0,6)
K=36

3
(0,7)
K=49

7
(0,8)
K=64

4
(0,9)
K=81

3
(0,10)
K=100

7
Figure 4.5. Fractal
generators
for selected values on the
yaxis of lattice points generated by
x^{2}+xy+y^{2}
= K. Animation and static versions.
Broadly speaking, we observe the
following
pattern (refer for this discussion to the static portion of Figure 4.5;
the colors match).
 (0,2), K=4.
Begin with the isosceles trapezoidal shape of the K=4 hierarchy.
 Note its bilateral symmetry
about a
vertical
line.
 Note that it takes two sides to
climb the
right side to the top of the generator
 (0,3), K=9.
For K=9, begin with the K=4 generator and
 add one full hexstep to the left
 add one half hexstep to the
right,
tucked
under at 120 degrees
 note that it takes three sides
to
climb the
right side to the top of the generator, one more than it did for the
"begin"
value
 (0,4), K=16.
For K=16, begin with the K=9 generator and
 add one half level part of a
hexstep to the
left
 note that it takes the same
number
of sides
to climb the right side to the top of the generator as it did in the
previous
case.
 (0,5), K=25.
For K=25, begin with the K=4 generator and
 add a full hexstep to the left
 add a full hexstep to the right
 note that it takes four sides to
climb the
right side to the top of the generator
 note the bilateral symmetry
about a
vertical
line
 (0,6), K=36.
For K=36, begin with the K=25 generator and
 add one full hexstep to the left
 add one half hexstep to the
right,
tucked
under at 120 degrees
 note that it takes one more side
to
climb
the right side to the top of the generator than it did for the "begin"
value
 (0,7), K=49.
For K=49, begin with the K=36 generator and
 add one half level part of a
hexstep to the
left
 note that it takes the same
number
of sides
to climb the right side to the top of the generator as it did in the
previous
case.
 (0,8), K=64.
For K=64, begin with the K=25 generator and
 add a full hexstep to the left
 add a full hexstep to the right
 note that it takes six sides to
climb the
right side to the top of the generator
 note the bilateral symmetry
about a
vertical
line
 (0,9), K=81.
For K=81, begin with the K=64 generator and
 add one full hexstep to the left
 add one half hexstep to the
right,
tucked
under at 120 degrees
 note that it takes one more side
to
climb
the right side to the top of the generator than it did for the "begin"
value
 (0,10), K=100.
For K=100, begin with the K=81 generator and
 add one half level part of a
hexstep to the
left
 note that it takes the same
number
of sides
to climb the right side to the top of the generator as it did in the
previous
case.
.........continue,
using the pattern without Figure 4.5.........
 (0,11), K=121.
For K=121, begin with the K=64 generator and
 add a full hexstep to the left
 add a full hexstep to the right
 note that it takes eight sides
to
climb the
right side to the top of the generator
 note the bilateral symmetry
about a
vertical
line
 (0,12), K=144.
For K=144, begin with the K=121 generator and
 add one full hexstep to the left
 add one half hexstep to the
right,
tucked
under at 120 degrees
 note that it takes one more side
to
climb
the right side to the top of the generator than it did for the "begin"
value
...............
After a number of
cases, there appears to be a clear pattern, colorcoded as
redgreenblue.
If that pattern is correct, then the reader could, through successive
(but
perhaps tedious) application of this pattern, produce a fractal
generator
for an arbitrary value on the yaxis. We will show a more
systematic
procedure later in this Chapter for finding generator size and shape;
it
will, however, be based on the observations above, so it is important
that
the reader have a clear understanding of them.
To produce
generators
for Kvalues not on the yaxis is also a simple matter of examining
pattern.
Figure 4.6 shows how to form generators for all other Kvalues
(not
on the yaxis) simply by adding hexsteps to the yaxis
Kvalue
generators as one moves to the right across lines of lattice points
parallel
to the line
y=x (cyan lines in Figure 4.7).
Thus, the reader could then form a fractal generator for an arbitrary Kvalue.
Yaxis value and line
position
Fractal generators off the yaxis
as determined by yaxis generator shape.
(0,0):
the
first generator appears for K=3 (not on the yaxis; K=0,
on the yaxis, is disregarded) and subsequent generators appear
for Kvalues of 12, 27, and 48 as one moves to the right across
the line y=x.

(0,1):
the
first generator appears for K=7 (not on the yaxis; K=1,
on the yaxis, is disregarded) and subsequent generators appear
for Kvalues of 19, 37, and 61 as one moves to the right across
the line displaced by 1 from, and parallel to, the line y=x.

(0,2):
the
first generator appears for K=4 and subsequent generators
appear
for Kvalues of 13, 28, 49, and 76 as one moves to the right
across
the line displaced by 2 from, and parallel to, the line y=x.

(0,3):
the
first generator appears for K=9 and subsequent generators
appear
for Kvalues of 21, 39, 63, and 93 as one moves to the right
across
the line displaced by 3 from, and parallel to, the line y=x.

Figure 4.6.
Fractal
generators are produced for arbitrary
Kvalues from yaxis
Kvalues.
See the cyan lines in Figure 4.7.
Fractal
Generation
of Arbitrary KValues: the Crosscut Equation as
a Systematic Characterization of Generator Size and Shape
In Figure 4.5, the
"red" category corresponds to a generator type similar to the K=4
generator: an isosceles trapezoid with some number of hexsteps
on
either side, producing a bilaterally symmetric form. The "blue"
category
corresponds to a generator type similar to the K=7 category,
identical
to the previous case but with one half level hexstep added to the
left.
If one looks at the trivial cases of K=0 and K=1 in
Figure
4.6, this style of pattern is evident in moving from K=3 to K=7.
Thus, it appears that there are really only three basic, or primitive,
styles of generator type: K=3 (green), K=4 (red), and K=7
(blue). Because generator shape on the yaxis determines
generator
shape off the axis along rays parallel to the line y=x (cyan
lines in Figure 4.7), we next consider partitioning the set of all K
values according to these three categories using a set of parallel rays
(cyan lines in Figure 4.7) to create that partition. Thus, we
seek
another equation to represent that partition with the intent of using
it
to cut across the Diophantine equation and provide straightforward
solution
to finding the number of sides and the shape of fractal generators for
arbitrary Kvalues.
The
pattern of numerical K values along rays parallel to y=x,
shown as cyan lines, is captured in Figure 4.7. Thus,
 along y=x,
we have K=3x^{2} : the K values
along
that ray, only, are generated exactly by substituting 0, 1, 2, 3, 4,...
into that equation yielding K values of 0, 3, 12, 27, 48, ...
 along the
ray
displaced
1 unit from the line y=x, we have K=3x^{2}+3x+1:
the K values along that ray, only, are generated exactly by
substituting
0, 1, 2, 3, 4,... into that equation yielding K values of
1, 7, 19, 37, 61,...
 along the
ray
displaced
2 units from the line y=x, we have K=3x^{2}+6x+4:
the K values along that ray, only, are generated exactly by
substituting
1, 2, 3, 4,... into that equation yielding K values of 4, 13, 28, 49,
76,...
 along the
ray
displaced
3 unit from the line y=x, we have K=3x^{2}+9x+9:
the K values along that ray, only, are generated exactly by
substituting
0, 1, 2, 3, 4,... into that equation yielding K values of 9,
21,
39, 63, 93,...
Equations for
y=x
and cyan rays parallel to y=x:
 K=3x^{2
}for
the line y=x
 K=3x^{2
}+
3x +1, for the cyan line displaced by 1
 K=3x^{2
}+
6x +4, for the cyan line displaced by 2
 K=3x^{2
}+
9x +9, for the cyan line displaced by 3

Figure 4.7.
Pattern suggesting crosscut equation. The equation for the cyan
rays, parallel to y=x, generate exactly the Kvalues
associated with lattice points along that ray (when integers are
substituted
into those equations..
Generalizing from
the observed pattern, it appears that the equation K=3x^{2
}+
3bx +b^{2}, where b counts the number of
units
the ray is displaced from y=x, will serve to capture all
the Kvalues associated with the lattice points along a single
horizontal
ray parallel to y=x (cyan, Figure 4.7), and to capture
no
others elsewhere. This idea is stated in the following theorem;
the
next chapter will present some of the number theoretic infrastructure
behind
it.
Fundamental
Theorem (S. Arlinghaus, 1985,
and
S. Arlinghaus in S. and W. Arlinghaus, 1989).
In a
triangular
central place lattice, the central place Kvalues, lying along
any
single one of the rays parallel to the line y=x, are
generated
by substituting nonnegative integral values into a quadratic equation K=3x^{2
}+
3bx +b^{2}=3x^{2}+3()x+()^{2},
where b=0, 1, ..., n,... counts the number of units the
ray
is
translated from y=x.
Thus, any single K
value has two quadratic equations that represent it. We now
proceed
to use properties of these quadratic equations to extract information
from
them sufficient to determine the number of fractal generator sides and
number of hexsteps for arbitrary K values from algebraic
information,
alone. Thus, an informed reader will have the capability to
replicate
the results, independent of relative position on any image. As an
analogy, this process is similar to using latitude and longitude as
numerical
measures to determine absolute position on the earthsphere rather than
using parallels and meridians as geometric measures to determine
relative
position on the earthsphere.
Number
of Generator Sides
The patterns observed appear often to involve partitions related to the
number 3. Thus, we consider a value based on divisibility by 3 as
one index.
Define an
integral
value j, using Kvalues along the yaxis, only,
as:
 If K
is congruent
to 0(mod 3), then j=()
/ 3;
 If K
is
not congruent
to 0(mod 3), then j=(()1)/3
or j=(()2)/3,
which
ever is an integer (clearly, both cannot be integersK leaves
either
a remainder of 1 or of 2 when divided by 3).
As some examples:
 when K=4,
then 4 is not evenly divisible by 3 so that K is not congruent
to
0(mod 3). Thus, one of j=(()1)/3
or j=(()2)/3
is
an integer. Indeed, j=(()2)/3
= (22)/3=0 is an integer.
 when K=9, then
9 is evenly divisible by 3 so that K is congruent to 0(mod
3).
Thus, j=() /
3 =
3/3 = 1.
 when K
= 16,
then 16 is not evenly divisible by 3 so that K is not congruent
to 0(mod 3). Thus, one of j=(()1)/3
or j=(()2)/3
is
an integer. Indeed, j=(()1)/3
= (41)/3=1 is an integer.
 when K=25,
then 25 is not evenly divisible by 3 so that K is not congruent
to 0(mod 3). Thus, one of j=(()1)/3
or j=(()2)/3
is
an integer. Indeed, j=(()2)/3
= (52)/3=1 is an integer.
 when K=36,
then 36 is evenly divisible by 3 so that K is congruent to
0(mod
3). Thus, j=()
/ 3 = 6/3 = 2.
 when K=49,
then 49 is not evenly divisible by 3 so that K is not congruent
to 0(mod 3). Thus, one of j=(()1)/3
or j=(()2)/3
is
an integer. Indeed, j=(()1)/3
= (71)/3=2 is an integer.
 when K=64,
then 64 is not evenly divisible by 3 so that K is not congruent
to 0(mod 3). Thus, one of j=(()1)/3
or j=(()2)/3
is
an integer. Indeed, j=(()2)/3
= (82)/3=2 is an integer.
 when K=81,
then 8 is evenly divisible by 3 so that K is congruent to 0(mod
3). Thus, j=()
/ 3 = 9/3 = 3.
 when K=100,
then 100 is not evenly divisible by 3 so that K is not
congruent
to 0(mod 3). Thus, one of j=(()1)/3
or j=(()2)/3
is
an integer. Indeed, j=(()1)/3
= (101)/3=3 is an integer.
 when K=121,
then 121 is not evenly divisible by 3 so that K is not
congruent
to 0(mod 3). Thus, one of j=(()1)/3
or j=(()2)/3
is
an integer. Indeed, j=(()2)/3
= (112)/3=3 is an integer.
 when K=144,
then 144 is evenly divisible by 3 so that K is congruent to
0(mod
3). Thus, j=()
/ 3 = 12/3 = 4.
...............
The examples
above
are colorcoded using the scheme of the geometric table to suggest
pattern
in the output of jvalues. What the pattern suggests is,
for
Kvalues
on the yaxis only,
 when K
is congruent
to 0(mod 3), then the number of sides for a fractal generator is given
by 2+4j
 when K
is not
congruent to 0(mod 3), then the number of sides for a fractal generator
is given by 3+4j.
Number
of Generator Hexsteps: Generator Shape
To count the number of hexsteps for an arbitrary Kvalue on
the
yaxis, we employ not only the jvalue calculated in the
previous
section, but also the wellknown discriminant (square root of (B^{2
}
4AC) in Ax^{2} + Bx + C) of a quadratic
form. Once again, we begin by considering a number of
examples
in order to study pattern and to piece it together with other pattern
that
is known. From the Fundamental Theorem, we know that
K=3x^{2}+3()x+()^{2}.
The discriminant of this equation is D = (3())^{2
}
4Â·3()^{2}=
9K
 12K = 3K. To count the number of hexsteps for a
fractal
generator for a yaxis
Kvalue, follow the strategy below:
 if K
is
congruent
to 0(mod 3) and
 if D
is congruent
to 1(mod 4), then the number of generator hexsteps is equal to the
greatest
integer in (2+4j)/2 =1+2j.
 if D
is congruent
to 0(mod 4), then the number of generator hexsteps is equal to the
greatest
integer in (2+4j)/2=1+2j.
 if K
is
not congruent
to 0(mod 3) and
 if j
is
even
(divisible by 2) then
 if D
is congruent
to 1(mod 4), then the number of generator hexsteps is equal to the
greatest
integer in (3+4j)/2.
 if D
is congruent
to 0(mod 4), then the number of generator hexsteps is equal to the
greatest
integer in (5+4j)/2.
 if j is
odd (not
divisible by 2) then
 if D
is congruent
to 1(mod 4), then the number of generator hexsteps is equal to the
greatest
integer in (5+4j)/2.
 if D
is congruent
to 0(mod 4), then the number of generator hexsteps is equal to the
greatest
integer in (3+4j)/2.
Looking at some
examples,
again, the colorcoding of redgreenblue shows that the number
theoretic
patterns provide an exact fit with the geometric pattern and they do so
without requiring seeing previous cases: the number theoretic
patterns
offer absolute measures, replicable independent of examination of
previous
cases.
Thus, for Kvalues
on the yaxis,
 when K=4,
then D = 3K = 12 which is evenly divisible by
4.
In addition, K is not congruent to 0(mod 3) and j=0
from
above, which is even. Thus, the number of hexsteps is the
greatest
integer in (5+4j)/2 which is 2.
 when K=9, then D
= 3K = 27 which is not evenly divisible by 4 and leaves a
remainder
of 1. In addition, K is congruent to 0(mod 3) and
j=1 from above. Thus, the number of hexsteps is the greatest
integer in 1+2j which is 3.
 when K
= 16,
then D = 3K = 48 which is evenly divisible by 4.
In addition, K is not congruent to 0(mod 3) and j=1 from
above, which is odd. Thus, the number of hexsteps is the
greatest
integer in (3+4j)/2 which is 3.
 when K=25,
then D = 3K = 75 which is not evenly divisible by 4
and
leaves a remainder of 1. In addition, K is not congruent
to
0(mod 3) and j=1 from above, which is odd. Thus, the
number
of hexsteps is the greatest integer in (5+4j)/2 which is 4.
 when K=36,
then D = 3K = 108 which is not evenly divisible by 4
and
leaves a remainder of 1. In addition, K is congruent
to 0(mod 3) and j=2 from above. Thus, the number of
hexsteps
is the greatest integer in 1+2j which is 5.
 when K=49,
then D = 3K = 147 which is not evenly divisible by
4.
In addition, K is not congruent to 0(mod 3) and j=2
from
above, which is even. Thus, the number of hexsteps is the
greatest
integer in (3+4j)/2 which is 5.
 when K=64,
then D = 3K = 192 which is evenly divisible by
4.
In addition, K is not congruent to 0(mod 3) and j=2 from
above, which is even. Thus, the number of hexsteps is the
greatest
integer in (5+4j)/2 which is 6.
 when K=81,
then D = 3K = 243 which is not evenly divisible by 4
and
leaves a remainder of 1. In addition, K is
congruent
to 0(mod 3) and j=3 from above. Thus, the number of
hexsteps
is the greatest integer in 1+2j which is 7.
 when K=100,
then D = 3K = 300 which is evenly divisible by
4.
In addition, K is not congruent to 0(mod 3) and j=3 from
above, which is odd. Thus, the number of hexsteps is the
greatest
integer in (3+4j)/2 which is 7.
 when K=121,
then D = 3K = 363 which is not evenly divisible by 4
and
leaves a remainder of 1. In addition, K is not congruent
to
0(mod 3) and j=3 from above, which is odd. Thus, the
number
of hexsteps is the greatest integer in (5+4j)/2 which is 8.
 when K=144,
then D = 3K = 432 which is not evenly divisible by 4
and
leaves a remainder of 1. In addition, K is
congruent
to 0(mod 3) and j=4 from above. Thus, the number of
hexsteps
is the greatest integer in 1+2j which is 9.
...............
Use
of the Fundamental Theorem
The
following
example shows how to determine the bvalue corresponding to an
arbitrary
Löschian number and therefore create a second
Diophantine expression
of that number. Suppose it has been determined, using the
sufficient
condition given in the Fundamental Theorem, that the number 397 is a
Löschian
number. Express 397 as 3x^{2} + 3bx +b^{2},
for some
b. To do so, consider values of b from 0 to
397^{1/2}. The greatest integer in this square root is
19.
Thus, possibilities for b range from 0 to 19. Because 3x^{2}
+ 3bx=397b^{2}, it follows that 397b^{2}
must be divisible by 3. This fact eliminates from further
consideration,
as b, any integer between 0 and 19 for which 397b^{2
}is
not a multiple of 3. These values are shown in the central column
of Table 4.2. Additionally, the material associated with the
Fundamental
Theorem states that the discriminant of the quadratic form, 3x^{2}
+ 3bx +b^{2} must be an integer. Thus, in
the
righthand column of Table 4.2 we calculate these discriminants for
each
of the candidate bvalues singled out in the central
column.
The only candidate b value that remains is b=1 and
therefore
the correct quadratic form to also associate with 397 is 3x^{2}
+ 3x +1. Geometrically, the ordered pair that generates
397
is represented as a lattice point that lies along the line b=1,
displaced one unit from the line y=x in the oblique
coordinate
system.
b
(397b^{2})/3
Square root of discriminant
0
132.333
a
1
132
4761^{1/2}=69
2
131
4752^{1/2}=68.934
3
129.333
a
4
127
4716^{1/2}=68.673
5
124
4689^{1/2}=68.476
6
120.333
a
7
116
4617^{1/2}=67.948
8
111
4572^{1/2}=67.616
9
105.333
a
10
99
4464^{1/2}=66.813
11
92
4401^{1/2}=66.340
12
84.333
a
13
76
4257^{1/2}=65.245
14
67
4176^{1/2}=64.621
15
57.333
a
16
47
3996^{1/2}=63.213
17
36
3897^{1/2}=62.425
18
24.333
a
19
12
3681^{1/2}=60.671
Table 4.2.
This table shows candidate values for b for K=397 in
the
lefthand column. It shows values of (397b^{2})/3
for each of those candidate values in the center column. The
righthand
column shows the square root of the discriminant of the quadratic
expression
3x^{2} + 3bx +b^{2} for different
values of b (from 0 to 19) that produce an integral value in
the
center column.
Now we have two
quadratic
equations to solve simultaneously to obtain the ordered pair that gives
rise to the Löschian value of 397.
397 = 3x^{2}
+ 3x + 1
397 = x^{2}
+ xy + y^{2}
Solving the first
equation
using standard techniques from high school algebra, and choosing the
positive
value, gives x = 11. Use that value of x to find y
= 12 in the second equation. There are no other
lattice
points that give rise to this particular Löschian number because there
is no other integral discriminant of the quadratic form 3x^{2}
+ 3bx +b^{2}.
The geometric characterization of the central place lattice as a set of
integral lattice points lying along a set of lines parallel to y
= x resulted, after some work, in a Fundamental Theorem that
permits
the algebraic determination of a quadratic form, 3x^{2}
+ 3bx +b^{2} , to generate a set of lattice
points
lying along a single line. When this second quadratic form was
applied
to the Diophantine equation,
K=
x^{2} + xy
+ y^{2} , easy calculations permit the determination of
the lattice coordinates associated with an arbitrary Löschian number
and of whether or not those coordinates are unique.
Uniqueness of Löschian
numbers:
solutions to previously unsolved problems.
Solving
the Kvalue Twin Hierarchy Problem
Dacey
noticed that some Kvalues have more than one central place
hierarchy
associated with them. Using classical methods, however, it is
difficult
to determine what these hierarchies might look like. Indeed,
Dacey
noted this issue as an unsolved problem in the classical geometry of
central
place theory. The fractal approach, when extended to arbitrary Kvalues,
permits solution of this unsolved problem using the Fundamental Theorem
and associated constructions.
Suppose
it has been determined that the number 49 is a Löschian
number.
Express 49 as 3x^{2} + 3bx +b^{2},
for some
b. To do so, consider values of b from 0 to
49^{1/2}. The greatest integer in this square root is
7.
Thus, possibilities for b range from 0 to 7. Because 3x^{2}
+ 3bx=49b^{2}, it follows that 49b^{2}
must be divisible by 3. This fact eliminates from further
consideration,
as b, any integer between 0 and 7 for which 49b^{2
}is
not a multiple of 3. These values are shown in the central column
of Table 4.3. Additionally, the material associated with the
Fundamental
Theorem states that the discriminant of the quadratic form, 3x^{2}
+ 3bx +b^{2} must be an integer. Thus, in
the
righthand column of Table 4.3 we calculate these discriminants for
each
of the candidate bvalues singled out in the central
column.
The only candidate b values that remains are b=2 and b=7
and therefore the correct quadratic forms to also associate with 49 are
3x^{2} + 6x + 4 and 3x^{2} + 21x
+49.
Geometrically, the ordered pairs that generate 49 are represented as a
lattice points that lies along the line b=2, displaced two units
from the line y=x in the oblique coordinate system, and
along
the line b=7, displaced seven units from the line y=x
in the oblique coordinate system.
b
(49b^{2})/3
Square root of discriminant
0
16.333
a
1
16
585^{1/2}=24.186
2
15
576^{1/2}=24
3
13.333
a
4
11
540^{1/2}=23.237
5
8
512^{1/2}=22.627
6
4.333
a
7
0
441^{1/2}=21
Table 4.3.
This table shows candidate values for b for K=49 in the
lefthand
column. It shows values of (49b^{2})/3 for each
of
those candidate values in the center column. The righthand
column
shows the square root of the discriminant of the quadratic expression 3x^{2}
+ 3bx +b^{2} for different values of b
(from
0 to 7) that produce an integral value in the center column.
Now we have two
sets
of two quadratic equations each to solve simultaneously to obtain the
ordered
pairs that gives rise to two different hexagonal hierarchies associated
with the Löschian value of 49.
49 = 3x^{2}
+ 6x + 4
49 = x^{2}
+ xy + y^{2}
49 = 3x^{2}
+ 21x + 49
49 = x^{2}
+ xy + y^{2}
In the first
set of equations, x=3 and y=5. In the second set,
x=0
and y=7. There are no other lattice points that give rise
to this particular Löschian number because
there is no other integral
discriminant, beyond these two, of the quadratic form 3x^{2}
+ 3bx +b^{2}. Thus, K=49 is
produced
either from the lattice point (0,7) on the yaxis or from the
lattice
point (5,3) not on the yaxis. Figure 4.8 illustrates the
two different fractal generators that give rise to the two different
hierarchies
using the procedure based on the Fundamental Theorem in associating
fractal
generators with lattice points.
Figure 4.8.
Geometric
solution of the K=49 twin hierarchy puzzle. The left
frame
shows an 11sided generator formed from the ordered pair (0,7) on the yaxis,
yielding a K=7 type of hierarchy. The right frame shows a
9sided generator formed from the ordered pair (5,3), not on the yaxis,
yielding a K=4 type of hierarchy.
This example
illustrates
the fact that the Fundamental Theorem solves, completely, the
previously
unsolved problem involving uniqueness, and its lack, in calculating
hexagonal
hierarchies. The geometric characterization of the central place
lattice as a set of integral lattice points lying along a set of lines
parallel to y = x resulted, after some work, in a
Fundamental
Theorem that permits the algebraic determination of a quadratic form, 3x^{2}
+ 3bx +b^{2} , to generate a set of lattice
points
lying along a single line. When this second quadratic form was
applied
to the Diophantine equation,
K= x^{2} + xy
+ y^{2} , easy calculations permit the determination of
the lattice coordinates associated with an arbitrary Löschian number
and also the determination of whether those coordinates are unique.
Putting
the Pieces Together
The material in the previous sections indicates a plausible strategy
for
producing appropriate fractal generators that will create, through
iteration,
exact central place hierarchies for arbitrary
Kvalues. It
does so using only number theoretic properties of two quadratic
forms.
Thus, process is replicable and independent of previous cases. In
the next chapter we consider some of the number theoretic
infrastructure
on which these methods rest and in a final chapter we present some real
world considerations.
Institute
of Mathematical Geography. Copyright, 2005, held by authors.
Spatial Synthesis:
Centrality and Hierarchy, Volume I, Book 1.
Sandra Lach Arlinghaus and
William Charles Arlinghaus
